Boshart PG25-200-GNL

Boshart PG25-200-GNL Stainless Steel Case Liquid General Purpose Pressure Gauge, 1/4 Inch Connection, 2-1/2 Inch Dial

  • Mfg. Name: Boshart
  • Brand Name: Boshart
  • MPN: PG25-200-GNL
  • PSCN: 450437
  • UPC: 777808327423
  • Min. Ord. Qty: 1
  • Qty. Interval: 1
  • Sold as pack of 50/Carton
Retail Price:
Qty
My List
Add / Remove CPN
  • General purpose - not for use with oxygen
  • Lead-free brass connection
  • 304 stainless steel case with vent plug
  • 140 deg F maximum media temperature

Standards/Certifications: ASME B40.1, ANSI Specified, NSF Approved

Applications: For Potable Water Pumps And Systems, These Gauges Are Suitable For Compressors, Hydraulic Presses, Machinery, Pneumatic Equipment And Motors, For Most Commercial Air, Water And Steam Services

Brand : Boshart
Item Name : Pressure Gauge
Type : Liquid, General Purpose
Gauge Range : 0 - 200 psi, 0 - 1400 kPa
Temperature Range : -40 to 140 deg F (Ambient), 140 deg F (Maximum)
Accuracy : +/-1.5%
Case Material : Stainless Steel
Dial Size : 2-1/2 Inch
Window Material : Polycarbonate
Connection Size : 1/4 Inch
Connection Type : MPT
Mounting : Lower/Center Back
Color : White
Dimensions : 2.68 Inch Diameter x 1.26 Inch Depth x 3.54 Inch Height
Increments : 2
Tube : Bourdon
Fill Type : Glycerine
Weight : 0.429 lb
