DiversiTech DSLD13-6SVHH

DiversiTech Virginia KMP AL-30-6SC Copper Suction Line Filter Drier, 3/4 Inch Sweat, 13 cu-Inch

  • Mfg. Name: DiversiTech
  • Brand Name: DiversiTech
  • MPN: DSLD13-6SVHH
  • PSCN: 224715
  • UPC: 0687472038238
  • Min. Ord. Qty: 1
  • Qty. Interval: 1
Retail Price:
Qty
My List
Add / Remove CPN

The solid-core clean-up dryer was developed for use in a system suction line. The compact design incorporates a large outside diameter shell, which results in a shorter lay-in length, and a larger core, which provides a greater filtration area for maximum operating efficiency. The core material has controlled porosity which effectively removes and holds a maximum amount of contaminants with a minimum of pressure drop. It collects and holds inorganic acids and other harmful contaminants from a motor burnout. This binding process protects the core from acid decomposition. Access valves on both the inlet and outlet sides make it easy to measure pressure accurately. Occasionally, enough contaminant matter may collect in the filter core to cause a slight pressure drop. The access valves on the SLD make it easy to determine if a pressure drop exists and to measure the amount of the drop. The original DSLD, solid core, activated alumina suction line filter dryer. High acid capacity. Low pressure drop – exceptionally high flow rates. Designed for system clean-up. 500 hr salt spray protection. Shortest system cut-out lengths allow installation in tight areas. Two access valves simplify pressure drop measurement. Flare or solid copper sweat fittings.

Standard/Approvals: UL Listed SA3441, CSA Certified LR46423

Item Name : Suction Line Filter Drier
Connection Size : 3/4 Inch
Connection Type : Sweat
Cubic Capacity : 13 cu-Inch
