Honeywell MS8105A1030

Honeywell MS8105 Direct Coupled Fast-Damper Valve Actuator, 24 VAC/VDC

  • Mfg. Name: Honeywell
  • Brand Name: Honeywell
  • MPN: MS8105A1030
  • PSCN: 351075
  • UPC: 85267433945
  • Min. Ord. Qty: 1
  • Qty. Interval: 1
Retail Price:
Qty
My List
Add / Remove CPN

Standard/Approvals: UL Listed 873, cUL C22.2 No. 24-93, CE Certified EMC 2004/108/EC, Certification Low Voltage Directive 2006/95/EC, IEC 60730-1 And Part 2-14

Application: For HVAC Application, Any Quarter-Turn, Final Control Elements Requiring Spring Return Fail-Safe Operation

Brand : Honeywell
Series/Model : MS8105
Item Name : Actuator
Type : Fast-Damper, Valve
Primary Voltage : 24 VAC/VDC
Frequency Rating : 50/60 Hz
Electrical Rating : 6/3 VA Driving
Temperature Range : -22 to 149 deg F Ambient, -40 to 150 deg F Storage
Connection Type : Enclosed Screw Terminal Strip (22 - 14 AWG)
Enclosure : NEMA 2, IP54
Dimensions : 6-81/54 Inch Height x 3-55/84 Inch Width x 3-5/32 Inch Depth
